ID Alarm Controller
Alarm transmission that is verified, not assumed. Contact ID over TCP/IP.
€125,00
Supplied under the ID Network product programme. We confirm compatibility, completeness and fit with you before anything ships. We verify. You decide.
Engineered by ID Network for installations where alarm transmission is verified, not assumed.
TCP/IP-Based Alarm and Device Control Controller
Overview
The ID Alarm Controller is a TCP/IP-based controller designed for device management and alarm signal transmission within security and automation systems. The controller enables monitoring and control of connected devices while providing reliable alarm communication to monitoring centers. The device can also operate as a local alarm monitoring unit with flexible arming and disarming methods including time schedules, TCP/IP commands, card readers, keypads, or combined authentication methods.
Key Features
- TCP/IP-based control and communication
- 8 programmable inputs supporting NO/NC configuration
- 3 relay outputs for alarm signaling and device control
- Local communication failure indication output
- Remote relay control via TCP/IP
- Integrated Ethernet interface
- Automatic arming based on configurable time schedules
- Flexible arming and disarming methods (TCP/IP, card reader, keypad)
- Alarm reporting using Contact ID format
- Secure communication with 256-bit AES encryption
System Architecture
The ID Alarm Controller operates within TCP/IP networks using a standard Ethernet interface. It connects security sensors to programmable inputs and controls devices via relay outputs. Alarm events and system notifications can be transmitted to central monitoring stations using standard Contact ID protocol. The controller can be integrated into existing access control or security infrastructures.
Technical Specifications
| Category | Specification |
|---|---|
| Power Supply | +12 VDC, 130 mA max |
| Operating Temperature | -40°C to +75°C |
| Programmable Inputs |
8 inputs, NO/NC configurable |
| Relay Output 1 | NO/NC relay, 1 A max, communication failure output |
| Relay Output 2 | NO/NC relay, 1 A max, controlled via TCP/IP |
| Relay Output 3 | NO/NC relay, 1 A max, controlled via TCP/IP |
| Low Voltage Notification | -15% of nominal voltage (configurable) |
| Network Interface |
RJ45 Ethernet |
| Supported Protocols | TCP/IP, DHCP, Telnet |
| Encryption |
256-bit AES |
| Alarm Output Format |
Contact ID |
Typical Applications
Security alarm systems • Building automation • Industrial monitoring • Remote site security • Integration with access control systems • Centralized alarm monitoring environments.
ID Alarm Controller provides a secure and scalable platform for monitoring, alarm transmission, and device control in modern network-based security systems.
